Two contrasting urban fabrics in Cairo, Egypt
People shape their cities in many ways and on many scales. Describe how socioeconomic factors can shaped the built environment from the entire city to the single public space. Discuss the most relevant example from the class/reading material and bring your own example from your own experience and observations
(Sustainable Development in Cities, USP 514 Class Discussion)
Homogenous Environmental seb-Zones. Part of a land suitability exercise along the Red Sea coast
Sustainability in both the natural and built environment is a major issue facing policy-makers, planners, developers and designers. There is no project, neighborhood or city that have yet achieved the right sustainability balance (the 3 Es). The assessment and exploration of existing built forms allows us to learn more about weaknesses that can be enhanced and improved in future projects, plans and designs.
(1) Based on the lecture and discussions in class, please write a single page introducing the most significant environmental components influencing the area you live in. Give examples of how such factors interact with or influence people’s life.
(2) In one page, mention and explain two major elements of the built environment that are crucial to sustainable development but not implemented properly in your area and will impact people’s quality of life.
(Sustainable Development in Cities, USP 514 Class Discussion)
By: Waleed Shehata
Historic Cairo contains possibly the finest and best surviving collection of more than 600 listed building, as well as its preserved urban fabric. Sorrowfully, sixty or more years ago, Cairo’s historic quarters have started facing deterioration symptoms. The long government neglect resulted in squatter settlements, diluted infrastructure and informal industries. This situation together with poor public awareness toward the value of heritage contributed to severe deterioration conditions for years. Despite dedicating a huge financial resources from the local government and international organizations the preservation, restoration and protection of historic Cairo’s monuments extend far beyond saving, or even restoring bricks and mortar for tourists. With conservation of the authentic fabric in mind, the adaptive reuse of Cairo’s heritage buildings is a recommended strategy for integrative revitalization and urban development of the historic city.
In architectural heritage conservation, adaptive reuse refers to the appropriate functional conversions of heritage buildings to suit the existing use or a proposed use. “The fact is that the best of all ways of preserving a building is to find a use for it, and then to satisfy so well the needs dictated by that use…” Viollet-le-Duc, 1854. The function is the most obvious change, but other alterations may be made to the building itself. Adapting a valuable building for reuse can include intensive exterior and interior modifications that are purely aesthetic and/or functional; such as the circulation route, the orientation, and spatio-physical relationships. In some cases the process of adaptive reuse may exceed the boundaries of the existing structure, or it may even necessitate the construction of an annex building depending on the peculiarities of the project. In other words, adaptive reuse includes any intervention to adjust, upgrade, introduce new services and uses to suit desired functional requirements, while safeguarding the place. The process itself should be applied to the building while retaining its structure, character, original identity and general authentic significance for future generations.
Thus, adaptive reuse of heritage buildings does not only step up the maintenance of the structure and delay its decay, but it also allows the functioning building to get involved in the living context it lies within, unlike buildings that are deserted and disused.
By: Mamdouh Sakr
One of the project’s clusters after the external plastering (still under construction)
Introduction
Architecture students and architects in Egypt and elsewhere seldom have the opportunity to study and understand the various techniques of Earth Construction. The majority of the architectural educational systems ignores such a topic completely, and restricts it to anthropological studies. This severe neglect of teaching the ancient yet sustainable building techniques is contemporaneous to a ruthless erosion of the Egyptian vernacular architecture, with all its architectural elements, decorative motifs and structural techniques.
Nowadays a number of projects are trying to benefit from the timeless building techniques and local materials to create sustainable, environment friendly and economical buildings.Most of these trials are a direct result of the efforts of Hassan Fathy, the late Egyptian architect who spent his entire career looking for and developing means of rebuilding communities that would allow people to live with self-respect despite their economic status.
The Project… The Idea
I was asked to design a touristic camp on a piece of land north of Nuweiba, which is a coastal town in the eastern part of the Sinai Peninsula, Egypt. An area, which is well known for its numerous “Bedouin-Style” camps, where tourists stay in cheap huts made of palm reeds and recycled plywood boards.
The “Bedouin- Style” hut seemed like a nice idea that has been abused by bad taste and limited budgets, and what started as an environment friendly, economical and aesthetically pleasing simple lodge turned to be an ugly ramshackle heap of different materials. After almost two decades of labeling the area as a “Hippie paradise”, things changed for a number of reasons and a camp composed of huts would never generate any income or even sustain the ownership of the plot. Sothe owners of the camps were obliged to build permanent rooms in addition to the simple huts.
The owner who was mesmerized by the beauty of the site wanted to respect the environment and create buildings that enhance the visitors’ experience of the sea, the desert and the mountains. The piece of land had a narrow frontage on the beach (90 meters), and this required a different design approach than the typical spreading of the rooms in rows parallel to the shoreline.Therefore the design gradually developed as a number of rooms clustered around courtyards that varied in size and form. These room clusters were placed organically in the natural desert landscape, ensuring natural lighting and ventilation to every unit.
Building Materials and Techniques
The use of natural materials and traditional building techniques was the main criterion, which influenced and guided the design of the camp. The available building materials in the site and the region were: stone shingles, silt, gravel and sand. Apart from these materials anything else had to be brought from the cities of the Nile Delta (almost 350 km away).
As the local volcanic and granite stones radiate large quantities of heat, they were unsuitable to build living spaces, but were easily used tobuildthe foundations. The presence of good-quality silt and sand encouraged the use of adobe, where only dry straw was needed to strengthen the mixture. So it was decided that adobe will be prepared in site, and used to build the walls, and the question was what will be used for the roofs. Unfortunately using reinforced concrete to create flat roofs became the norm in Egypt that most of the architects and clients do not even think of other options. I was trying to provide other environment friendly alternatives, however using wooden joists would not be that appropriate, as the materials, its preparing to withstand the harsh climate and the skilled labor involved would be extremely expensive. While I wanted to use adobe domes and vaults for environmental and aesthetic reasons, fortunately the owner accepted the idea because of its economical advantages and the overall ambiance, which would appeal and attract tourists visiting the camp. So we were simply using natural building materials and reusing Ancient Egyptian building techniques in the 21st century.
The Architect and the Mason
I can claim that earth building construction and traditional building techniques depend on the experience and ingenuity of the mason more than the creativity of the architect. The masons deliberately made some slight modifications, such as the sizes and location ofsome of the alcoves and a few decorative brick formations, where they felt that their modifications added a distinctive flair to the buildings.
I believe that such flexible relationship between the architect and the masons is peculiar to the earth building construction and is rarely present in the conventional building processes. This remark might raise an important question, whether these buildings are considered examples of “Vernacular” or“Neo-vernacular architecture”?
Addressing environmental problems is a concern for several international development organizations. The definition of “environmental” problems has been one of the obstacles to proper handling of the problem and allocating appropriate funding. Although this is true to a large extent, it is valid to argue that international aid is also bound by geopolitical forces and interest of the donating agency. Providing funding to address environmental problems is usually part of a larger cooperation agreement between governments or international agencies and therefore is derived by the interest and the agenda of the donor agency.
The definition is indeed a problem and this wide range (broad Vs narrow) of understanding plays a role in identifying and measuring the success of the program.
From previous experience, the following are some examples:
(1) Decision by central government is taken far from the location context and with absence of good knowledge of the context.
— The central government in Egypt developed a prototype for housing for the poor and named it (Taweteen). Spreading it out to remote areas of the country makes it extremely irrelevant and not suitable for the local tribes in the southern border near Sudan. This is because the lack of suitable design and absent of knowledge of the local conditions in such a remote area.
(2) Broad definitions is a problem, especially that most f the environmental and health issues are related to lack of infrastructures (i.e. water & sanitation).
— The environmental component of upgrading project end up of being a construction project instead of looking at the real environmental issues and resolve it. Again the absence of (appropriate technology) sometimes lead environmental improvement programs to be limited to installing pipes and provide urban utilities without proper needs assessment.
(3) Stand alone initiatives Vs Main stream: This paper argues that main stream is more important. Although this seem to be valid to a large extent. It is important not to ignore specific conditions where stand alone initiatives can also be equally important. Especially in initiatives that are newly introduced and can not be part of the original development framework. A good example is the initiatives of developing green stars for tourism establishments that consider all sustainability elements. It would not be a successful one if addressed as a continuation of the existing rating system.
(4) Pressure from Northern environmentalist.
— Either it is a blind copy of the developed world or a post colonial influence or looking forward to implementing good environmental practices from the North, the gap remains wide between the targeted and the achievable practices. A good step forward to transfer the good practices within the same region before looking forward to importing what might not work well from the North.
The Red Sea is a very unique resource that is not yet being utilized to its full potential. Since 1980s till today the mass tourism has destroyed large areas of coastal stretches of the northern Red Sea region and the city of Hurghada is an example for such environmental deterioration.
Innovative initiatives have taken place in order to protect the remaining parts of the red sea (From Marsa Alam city to South) including several guidelines by the Red Sea Sustainable Tourism Initiative (RSSTI) in 2000-2004 that focused on developing ecotourism and coastal planning for the region, followed by another pilot programme named Livelihood and Income From Environment (LIFE) in 2005-2008 which supported implementing pilot projects in national parks to demonstrate examples of the appropriate process. Since 2008 to date there has been several initiatives to introduce sustainable practices (i.e. Solid Waste Management, Mooring Buoys,..and other practices) lead by local NGOs such as HEPCA.
Despite all these attempts, the development pattern did not change much and the knowledge gained remains within a limited number of people, the main obstacles are: (i) An intuitional problem where the responsible authorities (both tourism and environment ministries) do not coordinate especially with such complexity of stakeholders, (ii) Practitioners are more inclined to utilize the Nile Valley architecture as the local and appropriate one for the Red Sea, and (iii) The lack of the understanding of the Red Sea system (i.e. drainage, soil, marine life,…and habitat) resulted to several inappropriate land subdivisions and allocating development in vulnerable areas
The solutions for such complex problems can be summarized as follow:
(i) Elevate the planning exercise above the ministry level, where planning is not limited to one ministry (housing, tourism, … and environment) that has a very specific mandate and will encourage mono-type of development, but rather an over arching exercise that is a product of a higher level proposed committee on the prime-minster level.
(ii) Improving the education (mainly architecture and planning) to incorporate appropriate planning tools and building technologies and not limit this arena to the Nile Valley architecture. Learning from the local tribes knowledge about best site selections criteria and building styles. Seeking guidance from relevant experiences in the region rather than copying western countries
(iii) Need for suitability land use maps that can guide development in the region without harmful intervention to the environment and being locally implementable within the local market dynamics
Also posted on the Berkeley Tourism Studies Working Group, (part of TSWG colloquium): http://www.tourismstudies.org/MiddleEast2013.htm
Picture taken from the Nile in Cairo looking at its western bank, Nov2013
The Nile, in general, and particularly in Cairo, is an ecological, cultural and social corridor that is not yet fully utilized. The 2011 Cairo workshop “Connecting Cairo to the Nile” identified the potential to increase accessibility to the river, suggested longitude trail system, proposed connecting the waterfront with adjacent neighborhoods and proposed expanding the ferry system. I studied a 2-km reach of the east bank in Maadi, a wealthy suburb about 10 km upstream of the city center, with relatively greener banks, availability of resources at the district level, higher awareness of local residents, physical setting allow for banks re-use, existence of community organizations (i.e. Tree Lovers and Midan). Findings of fieldwork and interviews show that: (i) species of native vegetation found are Phoenix Dactylifera, Jacaranda, Cortedarea and Papyrus alba; these are concentrated in 115 meter in southern part of the study area. (ii) Public access was categorized into: public space (accessible), private or semi-public space (accessible with conditions), and prohibited (inaccessible). Along this representative stretch of the Nile, the public access was limited to 16%, the private or semi-public makes 29% and the prohibited zones are 55%. (iii) Boating operations found to be in three categories, floating hotels (Nile cruises), motor boats (including ferries) and sailing boats, all are scattered along the banks without an overall plan or organization, which affects water flow and block public access to the banks. To better develop the banks, I recommend (i) maintaining existing riparian vegetation and expand it to other areas with healthy banks or planted nurseries, (ii) connecting open public spaces to create a pleasant walking trail along the banks in addition to improving public access by relocating government buildings (such as the police or military facilities) and facilitate access to the river for general public, (iii) reducing the anchoring points to two locations and redistribute boating operations to group all motor boats to use the ferry anchoring points and all the sailing boats to use Al-Yacht club marina.
